TPO Roofing Systems

Family Description

Our JM TPO roofing systems give you the option of a reliable, cost-effective roofing solution.

We reinforce our membranes with a polyester fabric and manufacture them using an ultraviolet-resistant thermoplastic polyolefin formulation.

We developed our TPO formulation to allow for extreme pliability, flexibility and weldability during the installation.

Products

TPO Membranes

JM TPO Fleece Backed Membrane
JM TPO Fleece Backed Roofing Membrane has an integral polyester fleece backing that provides flexibility.
JM TPO Fleece Backed Membrane for Hot Asphalt Application
TPO Heavy-Fleece Backed Membrane for Hot Asphalt Application in hybrid systems. Installing a redundant, multi-ply, monolithic hybrid system ensures dependability, energy savings and lower maintenance costs.
JM TPO Roofing Membrane
JM TPO gives you a more cost-effective, yet highly reliable solution for your roofing projects. Our membranes are reinforced with a polyester fabric and manufactured with an ultraviolet-resistant thermoplastic polyolefin formulation. This combination provides you with extreme pliability, flexibility and weldability.
JM TPO SA
JM TPO SA (Self-Adhered) membranes can be installed up to three times faster than a traditional fully adhered application through the “peel and stick” technology of our factory-applied adhesive. TPO SA works great for installations that require little to no VOCs and may also have fewer weather restrictions than many traditional adhesive systems. JM TPO SA starts strong and stays strong for the full life of the roof.

Vapor Barriers

JM Vapor Barrier SA
JM Vapor Barrier SA is a self-adhered membrane and can be installed on plywood, gypsum or concrete board, concrete, asphalt or metal after the substrate has been primed.
JM Vapor Barrier SAR
JM Vapor Barrier SAR is a self-adhered membrane with a fiber glass reinforcement and can be installed on plywood, gypsum or concrete board, concrete, asphalt or metal after the substrate has been primed.

TPO Accessories

JM 3oz Polyester Slipsheet
Needle-punched, non-UV resistant polyester separation layer used for TPO, PVC, and EPDM mechanically fastened systems and ballasted EPDM systems.
JM Polyester Mat Protection Slipsheet
Polyester 9.0oz needle-punched UV-resistant fabric utilized as cushioning, separation or a protective layer for single ply systems.
JM Single Ply Safety Strip
Provides a visual and physical safety warning on roof top areas of caution and potential hazards.
JM TPO Coated Metal
Nonreinforced JM TPO membrane laminated with galvanized steel to be fabricated into metal flashings and edge details.
JM TPO Cover Tape
TPO cover tape is a flexible, non-reinforced TPO membrane used to strip-in metal flanges.
JM TPO Curb Flashing
JM TPO Curb Flashing is a 60 mil reinforced TPO membrane with an encapsulated edge used on curbs and parapet walls.
JM TPO Detail Membrane
Use JM TPO Detail Membrane to easily form flashings around corners and penetrations. Specifically designed for use in areas that cannot be properly detailed with TPO field membrane. This material is a flexible, non-reinforced TPO (thermoplastic polyolefin).
JM TPO Heat Weldable Cover Tape
TPO Heat Weldable Cover Tape is a 6" wide, flexible, reinforced TPO membrane used to strip-in metal flanges.
JM TPO Peel and Stick 10 Inch Reinforced Perimeter Strips (RPS)
TPO Peel and Stick RPS is a 45 mil (1.14 mm) thick reinforced TPO (thermoplastic polyolefin) membrane with 30 mil (0.76 mm) thick, factory-applied peel and stick adhesive tape.
JM TPO Peel and Stick 6 Inch Reinforced Termination Strip (RTS)
TPO Peel and Stick RPS is a 45 mil (1.14 mm) thick reinforced TPO (thermoplastic polyolefin) membrane with 30 mil (0.76 mm) thick, factory-applied peel and stick adhesive tape.
JM TPO Penetration Pocket
Two-piece, molded unit with a rounded base flange used to seal uneven or irregular penetrations.
JM TPO Pipe Boots
Flexible, non-reinforced TPO membrane used to flash vent stacks and round penetrations.
JM TPO Pipe Boots (Peel and Stick)
Flexible, nonreinforced TPO membrane applied to flash vent stacks and round penetrations.
JM TPO Pre-Molded Corners
Designed for use as an inside corner or outside corner on all TPO thermoplastic roof systems.
JM TPO Reinforced Cover Strip
62 mil reinforced, heat-weldable TPO membrane used to cover exposed discs or fasteners.
JM TPO Round Split Pipe Boot
A prefabricated, reinforced 60 mil JM TPO, round-shaped 1" to 6" (2.54 cm to 15.24 cm) split-pipe boot for flashing application. Pipe boots minimize the need for field fabrication.
JM TPO Safety Walkpad
Textured, non-reinforced TPO walkpad that provides a safe, stable and maintenance-free walkway for quick and easy access to rooftop equipment in high traffic areas.
JM TPO T-Joint Patch
Flexible, nonreinforced TPO membrane used to cover joints, discs and fasteners on the membrane.
JM TPO Universal Corners
Flexible, nonreinforced, waffle-patterned TPO membrane used around inside and outside corners.
JM TPO Walkpad
Textured, flexible TPO membrane intended for use as walkway material and protection around high-traffic areas. Provides a safe, stable and maintenance-free walkway for quick and easy access to rooftop equipment in high traffic areas.
JM White EPDM Peel and Stick Flashing
Easily forms flashings around corners and penetrations that cannot be properly detailed with TPO membrane.
JM White EPDM Peel and Stick Inside/Outside Corners
Easily forms flashing around corners and penetrations for specific TPO applications.
TPO Square Pipe Boot
A prefabricated, reinforced 60 mil JM TPO, square boot in 2" and 4" (5.08 cm and 10.16 cm) sizes for tube-flashing application. Pipe boots minimize the need for field fabrication.

Adhesives, Cements, Sealants and More

JM All Season Sprayable Bonding Adhesive, Accessories, and Flush
JM All Season Sprayable Bonding Adhesive is an aerosol bonding adhesive that can be used for TPO and EPDM adhered roofing systems and wall flashings. The JM All Season adhesive complies to Low VOC requirements and is a contact adhesive requiring two-sided application. JM All Season Sprayable Bonding Adhesive can also be used as a primer for JM Self Adhered Vapor Barriers.
JM LVOC Membrane Adhesive - TPO and EPDM
JM LVOC Membrane Adhesive is a one-part, low VOC synthetic polymer-based membrane adhesive.
JM Membrane Bonding Adhesive - TPO and EPDM
JM Membrane Bonding Adhesive is used for adhering JM TPO and EPDM membranes to approved substrates.
JM One-Part Liquid Flashing Kit - Single Ply
JM One-Part Liquid Flashing Kit - Single Ply comes with the JM One Part Pourable Sealer combined with the JM PermaFlash scrim which are ideal for creating a uniform, self-terminating liquid flashing system for use with TPO, EPDM, & PVC.
JM One-Part Pourable Sealer
JM One-Part Pourable Sealer is used as a penetration pocket filler.
JM One-Step Foamable Adhesive
JM One-Step Foamable Adhesive is a polyurethane adhesive for attaching insulation/cover boards to the roof deck or other insulation boards.
JM Roofing System Urethane Adhesive - RSUA
JM Roofing System Urethane Adhesive is a two-component polyurethane adhesive.
JM Single Ply LVOC Caulk
Single Ply LVOC Caulk is used to seal flashing terminations, peel and stick products, and exposed edges of JM membrane cement splices.
JM Single Ply Membrane Cleaner - Low VOC
Single Ply Membrane Cleaner is used to remove dirt, asphalt or other contaminants from JM TPO and PVC single ply membranes to ensure a good weld or bond. Can be used prior to applying TPO Membrane Primer for peel and stick applications.
JM Single Ply Membrane Primer - Low VOC
JM Single Ply Membrane Primer (LVOC) is a synthetic polymer-based Primer for JM TPO and EPDM Membrane surfaces.
JM Single Ply Sealing Mastic
Single Ply Sealing Mastic is used to seal JM Single Ply membranes to terminations and other penetrations.
JM TPO 1168 Membrane Adhesive
JM TPO 1168 Membrane Adhesive is used for adhering JM TPO and JM EPDM membranes to approved substrates. Do not use on fleece-backed membranes at any time.
JM TPO LVOC Edge Sealant
TPO LVOC Edge Sealant is used to seal cut edges of JM TPO membranes.
JM TPO Membrane Cleaner
TPO Membrane Cleaner is a one-part solvent cleaner used to remove dirt, asphalt or other contaminants from TPO membranes.
JM TPO Membrane Primer
JM TPO Membrane Primer is a one-part membrane primer used to prepare surface for adhering TPO peel-and-stick products.
JM TPO Pourable Sealer
TPO pourable sealer is used to fill penetration pockets on TPO roofing systems.
JM TPO Water Based Membrane Adhesive
JM TPO Water Based Membrane Adhesive is a polymeric adhesive designed for bonding TPO membranes to approved roofing substrates.
JM Two-Part Pourable Sealer
JM Two-Part Pourable Sealer is a two-part sealant used as a penetration pocket filler.
JM Two-Part Urethane Insulation Adhesive
JM Two-Part UIA is a Two-part cold-application adhesive used to adhere insulation board products to approved roofing substrates, and insulation to insulation.
JM Two-Part Urethane Insulation Adhesive (UIA) Canister
JM Two-Part Urethane Insulation Adhesive (UIA) Canister is a two-component polyurethane adhesive used for attaching fleece-backed membranes to insulation and insulation boards to the roof deck or to other insulation boards.
JM Weathered Membrane Cleaner
JM Weathered Membrane Cleaner cleans the release agent and dirt from JM TPO and JM EPDM membranes.
SA Primer
SA Primer is composed of SBS synthetic rubbers, adhesive enhancing resins and volatile solvents.
SA Primer Low VOC
SA Primer Low VOC is composed of SBS synthetic rubber and adhesive-enhancing resins.

Insulation and Cover Boards

DEXcell Cement Roof Board
DEXcell Cement Roof Board is a cover board that is able to withstand prolonged exposure to moisture and meets FM Class 1 fire barrier requirements.
DEXcell FA Glass Mat Roof Board
DEXcell FA Glass Mat Roof Board is a cover board with a heavy duty coated fiber glass facer. It is moister and mold resistant and meets FM Class 1 fire barrier requirements.
DEXcell Glass-Mat Roof Board
DEXcell Glass-Mat Roof Board is a gypsum cover board that can be used in mechanically fastened single ply systems.
DEXcell® FA VSH Glass Mat Roof Board
DEXcell® FA VSH Glass Mat Roof Board is competitively priced, easier to install and very severe hail strong to withstand the harshest conditions over the long haul.
DensDeck Prime Roof Board
DensDeck Prime Roof Board is a gypsum cover board with an enhanced coated glass mat facer
DensDeck Roof Board
DensDeck Roof Board is a gypsum cover board with a glass mat facer.
DensDeck StormX Prime Roof Board
DensDeck StormX Prime Roof Board contains an enhanced coated glass mat facer and achieves FM's VSH approval in select JM TPO systems.
ENRGY 3 - Flat and Tapered
ENRGY 3® is a closed-cell polyisocyanurate foam core insulation board offering a high R-value to keep your building well insulated from the elements.
ENRGY 3 CGF - Flat and Tapered
ENRGY 3® CGF is a closed-cell polyisocyanurate foam core with an inorganic-coated glass facer on each side. It offers high R-value per inch and achieves a UL Class A approval in select systems.
ENRGY 3 HD
ENRGY 3® HD is a closed cell polyisocyanurate foam technology provides additional insulation value (R-value of 2.5), with lightweight and high density characteristics.
ProtectoR Foam
Dual-Density Polyisocyanurate Composite Board produced with our High-Density ProtectoR® HD cover board and our standard-density Foam (ENRGY® 3 CGF).
ProtectoR HD
ProtectoR® HD is a high-density polyiso cover board that provides excellent resistance against harsh rooftop conditions including hail, wind uplift, puncture and moisture.
RetroPlus Roof Board
RetroPlus™ Roof Board is a high-density, expanded, perlite-based cover board engineered to optimize system performance across all applications.
SECUROCK Cement Roof Board
SECUROCK Cement Roof Board is ideal for liquid applied membrane roof systems. It has superior wind-uplift performance for a wide variety of roof assemblies and excellent fire performance.
SECUROCK Gypsum-Fiber Roof Board
SECUROCK Gypsum-Fiber Roof Board contains a integral water-resistant core and has excellent fire performance.
SECUROCK Ultralight Glass-Mat Roof Board
SECUROCK Ultralight Glass-Mat Roof Board is a gypsum cover board with fiber glass facer and back.
SeparatoR
SeparatoR® provides an economical solution for mechanically fastened single ply membrane recover applications while adding thermal insulation value to your building.
SeparatoR CGF
SeparatoR® CGF is a versatile, ½"-thick cover board solution that is designed for re-cover applications and offers performance and value.

Fasteners and Plates

All Purpose Fasteners
All Purpose Fasteners are #14 case-hardened steel fasteners with a #3 Phillips head. The point is designed for quick installation in new or re-roof applications.
Extra High Load Fasteners and Plates
Extra High Load #21 fasteners, #3 Phillips head and a drill point contain a corrosion-resistant coating and to be used to mechanically attach thermoplastic membranes.
High Load AccuSeam System
The High Load AccuSeam™ System is a premier automated system for mechanically attached seams. The System positions the 23⁄8" (6.03 cm), round, High Load Plate with eye hooks, and installs the High Load Fastener, up to 6" (15.24 cm) in length in a one-step, continuous process. Standard High Load Plates are not compatible with the AccuSeam™ Fastener and Plate System
High Load Fasteners and Plates
High Load Fasteners are a #15 case-hardened steel roof membrane fastener with Galvalume®*-coated steel seam plates. These fasteners can be used in a thermoplastic induction weld system with RhinoPlate®.
JM ENRGY Anchor
ENRGY® Anchor is a lightweight, roof-top integrated, photovoltaic (PV)-mounting solution consisting of a Galvalume®*-coated steel plate welded to a stainless steel stud, with a JM membrane flashing target. Each assembly includes a leveling washer and membrane separator.
JM Purlin Fastener
The JM Purlin Fastener is a steel-coated fastener with a ¼" hex head and ¾" (19 mm) drill point. The drill point allows the fastener to be drilled through the purlin before the threads engage into the standing seam metal roof.
JM RetroDriller Fasteners
JM RetroDriller Fastener is designed for attaching single ply membrane systems to structural purlins (up to 3 /16”) in standing seam metal roof retrofit applications.
JM TPO RhinoPlate
JM TPO RhinoPlate® is a 3" (76.2 mm) round specially coated Galvalume®* plate with a recessed center and raised flat bonding surface. The JM TPO RhinoPlate® is a roof attachment system that uses heat induction technology
JM Termination Systems
JM Termination Systems include termination bars, anchor discs and masonry nail-in anchor and are used for membrane fastening systems.
JM VSH Plate
JM VSH Plates are 2.2" round heavy duty reinforced polymer plates with barbs utilized for in seam single ply membrane securement, and cover board preliminary securement of Very Severe Hail rated single ply membrane systems.
JM isoweld
JM isoweld® is 3.12" (79.2 mm) round G-90 steel plate with a flat bonding surface of proprietary TPO or PVC adhesive coating. Utilizing induction weld technology, JM isoweld® simultaneously fastens the insulation and membrane. Designed to be used with JM #15 Dekfast Fasteners.
Lite-Deck Fasteners and Plates
Lite-Deck Fasteners are available in lengths from 25 /8” to 12" (67 mm to 305 mm), come with a square drive and offer coarse thread to provide high pullout resistance.
Membrane Battens
Membrane Battens are a 1" wide, prepunched, polymer batten strips with prepunched, counter-sunk, GALVALUME®*-coated steel anchor bars.
Polymer Auger Fasteners
Polymer Auger Fasteners are glass-reinforced nylon fasteners with an internal ¼" (6 mm) square drive. Polymer Auger Fasteners have a 1" (2.5 cm) diameter head.
Structural Concrete Deck Fasteners and Plates
The Structural Concrete Deck Fastener is a diamond point, non-threaded carbon steel insulation and membrane fastener.
UltraFast AccuTrac Fastener and Plate System
The UltraFast® AccuTrac™ Fastener and Plate System utilizes the standard UltraFast® Fastener and the UltraFast® Accutrac™, recessed or flat bottomed, square plate. The AccuTrac™ tool positions the plate and installs fasteners 15⁄8" - 6" (4.13 cm - 15.24 cm) in a one-step process. Consistent vertical alignment of fasteners ensures maximum thread engagement and pullout performance.
UltraFast Fasteners and Plates
UltraFast® Fasteners and Plates are used to fasten insulation in both multi-ply and single ply systems. The UltraFast® Fastener is a #12, case-hardened steel, polymer-coated fastener with a buttress thread design that provides maximum pullout values and minimizes fastener backout. The UltraFast® Plates are either round, high strength polypropylene plates with a special locking feature or round or square, premium Galvalume®*-coated steel metal plates.
UltraLok Locking Impact Fastener and Plate
UltraLok™ Locking Impact Fasteners and Plates consist of a preassembled Galvanized steel tube, a 2.7" (6.86 cm) Galvalume®*-coated steel disc, and a precision-formed, coated- steel, high tensile, wirelocking staple. The disc is securely clamped to the tube and is rib-reinforced to resist cupping.

Liquid Applied

JM SP Liquid Flashing Concrete Primer
JM SP Liquid Flashing Concrete Primer is used to prime properly prepared and abraded concrete and masonry substrates that comes into contact with JM single ply membranes as part of the JM SP Liquid Flashing System.
JM SP Liquid Flashing Metal and Wood Primer
JM SP Liquid Flashing Metal and Wood Primer is used to prime properly prepared and acceptable metal and wood substrates that comes into contact with JM single ply membranes as part of the JM SP Liquid Flashing system.
JM SP Liquid Flashing Resin
JM Single Ply Liquid Flashing Resin is a two-part, cold-applied, polyurethane-based product that creates a uniform self-terminating flashing ideal for tying together JM single ply membranes with most common roofng materials.
JM SP Liquid Flashing Scrim
JM SP Liquid Flashing Scrim is a polyester based, nonwoven reinforcement fabric used in the JM SP Liquid Flashing system. The soft, flexible fabric is designed for use around oddly shaped, difficult penetrations and tying together different roofing substrates.
JM SP Liquid Flashing TPO and PVC Primer
JM SP Liquid Flashing TPO and PVC Primer is used to prime the JM TPO and PVC (KEE and SD Plus) single ply membranes as part of the JM SP Liquid Flashing system.

Coatings

JM Coating Acrylic
JM Coating Acrylic is designed for use as a reflective top coat either over built-up, modified bitumen, or mechanically attached or adhered aged TPO or PVC membranes.
JM Coating Acrylic CR
JM Coating Acrylic CR is designed for use as a reflective top coat either over built-up, modified bitumen, or mechanically attached or adhered aged TPO or PVC membranes.
JM Coating Acrylic Flashing
Designed for use over a variety of substrates, JM Coating Acrylic Flashing is a reinforced flashing mastic used for repair applications, or to seal common flashing conditions when using JM Coating Acrylic and JM Coating Acrylic CR.
JM Coating Field Polyester Reinforcing Fabric
JM Coating Field Polyester Reinforcing Fabric is a firm stitch-bond polyester used in JM Coatings systems.
JM Coating Polyester Reinforcing Fabric
JM Coating Field Polyester Reinforcing Fabric is a non-woven, fabric reinforcement.
JM Coating Repair Tape
JM Coating Repair Tape is used to seal seams, flashings and repair areas of existing roof prior to application of JM Coating Membrane systems.
JM Coating Silicone
JM Coating Silicone is designed for use over a variety of substrates, including built-up, modified bitumen, and aged mechanically attached or adhered TPO and EPDM membranes.
JM Coating Silicone Flashing
Designed for use over a variety of substrates, JM Coating Silicone Flashing is a mastic used for repair applications with a reinforcing fabric, or to seal common flashing conditions when using JM Coating Silicone.
JM Coating Single Ply Primer
JM Coating Single Ply Primer is an adhesion promoter for use on aged single ply surfaces prior to application of the JM Acrylic or Silicone Coatings.
TopGard 4000
One-part, acrylic reflective coating (in white or tan) for bituminous and single ply roof systems.
TopGard 5000
One-part, acrylic reflective coating for bituminous or single ply roof systems.
TopGard Base Coat

One-part, acrylic base coating (for TopGard® 4000 or 5000) that acts as an oil-bleed barrier for bituminous systems.

Specialty Roofing Products

Expansion Joint Cover - PVC EJ/WC
Expand-O-Flash® Style PVC EJ/WC is an expansion joint with reinforced PVC cover to weld the joint assembly to the PVC membrane.
Expansion Joint Cover - Style CF - Curb to Curb
Elastomeric bellows supported by a closed-cell foam backer for installation on wood curbs.
Expansion Joint Cover - Style CF/EJ - Curb to Wall
Elastomeric membrane bellows supported by a closed cell foam backer.
Expansion Joint Cover - Style EJ - Cant to Cant
Elastomeric membrane bellows for installation on roof-to-roof conditions.
Expansion Joint Cover - Style EJ - Cant to Wall
Elastomeric membrane bellows for installation on roof-to-wall installations.
Expansion Joint Cover - Style EJ/WC - Curb to Curb
Elastomeric or PVC membrane supported by a closed-cell foam backer.
Expansion Joint Cover - Style EJ/WC - Curb to Wall
Elastomeric or PVC membrane for installation on any width curb.
Expansion Joint Cover - TPO EJ/WC
Expand-O-Flash® expansion joint covers are flexible, weather-proof exterior covers for expansion joint openings and are an effective, flexible closure for a wide variety of standard and special applications.
Heavy-Duty TPO RetroDrain
One-piece spun aluminum body, TPO-coated flange and depressed sump area used to replace existing drains in re-roofing applications.
Hercules RetroDrain
One-piece spun aluminum body, heavy-duty cast aluminum dome/clamping ring and depressed sump area and is designed for use in all roofing systems.
OverFlow and FlowControl
Spun aluminum round drain attachment for use with all RetroDrains.
PVC AlumaWeld RetroDrain
AlumaWeld® RetroDrain® is a one-piece spun aluminum body, plastisol-coated flange and depressed sump area used in PVC roof systems to replace existing drains in re-roofing applications.
Presto Lock Coping System
A cost-effective snap-on coping system designed for use with single ply, built-up and modified bitumen roofing systems. The system consists of galvanized steel anchor clips and aluminum or galvanized coping covers in a variety of thicknesses and colors.
Presto-Tite Edge One Fascia System
Edge One Fascia system offers convenience and economical pricing to simplify projects and maximize profits. Our Edge One Fascia for single-ply roofs helps to protect the roof system against high wind events, saving the building from costly damage. The design eliminates the stripping in typical of other products, making Edge One Fascia fast and easy to install.
Presto-Tite Fascia System (Bituminous Systems)
A high performance edge treatment for all modified bitumen and BUR roof projects. Nonpenetrating design allows for vertical face attachment without penetrating the horizontal flange, and eliminates the need to strip-in the deck flange, eliminating potential delamination between the asphalt and metal deck flange due to thermal expansion and contraction forces. Provides maximum protection against wind uplift damage.
Presto-Tite Fascia System (Single Ply Systems)
A high performance edge treatment for fully adhered or mechanically fastened single ply roof projects. Nonpenetrating design allows for vertical face attachment without penetrating the horizontal flange, and eliminates the need to strip-in the deck flange, eliminating potential delamination between the adhesive and metal deck flange due to thermal expansion and contraction forces. Provides maximum protection against wind uplift damage.
Presto-Weld Drip Edge
Presto-Weld drip edge is a factory-fabricated coated metal edge system used to terminate at the perimeter of a PVC or TPO membrane. This edge comes with a factory applied, 8" wide PVC flashing strip or 6" wide TPO flashing strip of Johns Manville membrane to help save labor installation costs in the field. Presto-Weld is an economical solution for many conditions such as continuous edge drainage with or without a gutter condition.
U-Flow Screwdriver
The U-Flow Screwdriver is an extra long screwdriver to tighten the special recessed head screws on U-Flow compression seals.
Vertical Expansion Joint Cover
Elastomeric membrane bellows and 4" metal flanges for use with vertical expansion joints.

TPO Membranes

JM TPO Fleece Backed Membrane
JM TPO Fleece Backed Roofing Membrane has an integral polyester fleece backing that provides flexibility.
JM TPO Fleece Backed Membrane for Hot Asphalt Application
TPO Heavy-Fleece Backed Membrane for Hot Asphalt Application in hybrid systems. Installing a redundant, multi-ply, monolithic hybrid system ensures dependability, energy savings and lower maintenance costs.
JM TPO Roofing Membrane
JM TPO gives you a more cost-effective, yet highly reliable solution for your roofing projects. Our membranes are reinforced with a polyester fabric and manufactured with an ultraviolet-resistant thermoplastic polyolefin formulation. This combination provides you with extreme pliability, flexibility and weldability.
JM TPO SA
JM TPO SA (Self-Adhered) membranes can be installed up to three times faster than a traditional fully adhered application through the “peel and stick” technology of our factory-applied adhesive. TPO SA works great for installations that require little to no VOCs and may also have fewer weather restrictions than many traditional adhesive systems. JM TPO SA starts strong and stays strong for the full life of the roof.

Vapor Barriers

JM Vapor Barrier SA
JM Vapor Barrier SA is a self-adhered membrane and can be installed on plywood, gypsum or concrete board, concrete, asphalt or metal after the substrate has been primed.
JM Vapor Barrier SAR
JM Vapor Barrier SAR is a self-adhered membrane with a fiber glass reinforcement and can be installed on plywood, gypsum or concrete board, concrete, asphalt or metal after the substrate has been primed.

TPO Accessories

JM 3oz Polyester Slipsheet
Needle-punched, non-UV resistant polyester separation layer used for TPO, PVC, and EPDM mechanically fastened systems and ballasted EPDM systems.
JM Polyester Mat Protection Slipsheet
Polyester 9.0oz needle-punched UV-resistant fabric utilized as cushioning, separation or a protective layer for single ply systems.
JM Single Ply Safety Strip
Provides a visual and physical safety warning on roof top areas of caution and potential hazards.
JM TPO Coated Metal
Nonreinforced JM TPO membrane laminated with galvanized steel to be fabricated into metal flashings and edge details.
JM TPO Cover Tape
TPO cover tape is a flexible, non-reinforced TPO membrane used to strip-in metal flanges.
JM TPO Curb Flashing
JM TPO Curb Flashing is a 60 mil reinforced TPO membrane with an encapsulated edge used on curbs and parapet walls.
JM TPO Detail Membrane
Use JM TPO Detail Membrane to easily form flashings around corners and penetrations. Specifically designed for use in areas that cannot be properly detailed with TPO field membrane. This material is a flexible, non-reinforced TPO (thermoplastic polyolefin).
JM TPO Heat Weldable Cover Tape
TPO Heat Weldable Cover Tape is a 6" wide, flexible, reinforced TPO membrane used to strip-in metal flanges.
JM TPO Peel and Stick 10 Inch Reinforced Perimeter Strips (RPS)
TPO Peel and Stick RPS is a 45 mil (1.14 mm) thick reinforced TPO (thermoplastic polyolefin) membrane with 30 mil (0.76 mm) thick, factory-applied peel and stick adhesive tape.
JM TPO Peel and Stick 6 Inch Reinforced Termination Strip (RTS)
TPO Peel and Stick RPS is a 45 mil (1.14 mm) thick reinforced TPO (thermoplastic polyolefin) membrane with 30 mil (0.76 mm) thick, factory-applied peel and stick adhesive tape.
JM TPO Penetration Pocket
Two-piece, molded unit with a rounded base flange used to seal uneven or irregular penetrations.
JM TPO Pipe Boots
Flexible, non-reinforced TPO membrane used to flash vent stacks and round penetrations.
JM TPO Pipe Boots (Peel and Stick)
Flexible, nonreinforced TPO membrane applied to flash vent stacks and round penetrations.
JM TPO Pre-Molded Corners
Designed for use as an inside corner or outside corner on all TPO thermoplastic roof systems.
JM TPO Reinforced Cover Strip
62 mil reinforced, heat-weldable TPO membrane used to cover exposed discs or fasteners.
JM TPO Round Split Pipe Boot
A prefabricated, reinforced 60 mil JM TPO, round-shaped 1" to 6" (2.54 cm to 15.24 cm) split-pipe boot for flashing application. Pipe boots minimize the need for field fabrication.
JM TPO Safety Walkpad
Textured, non-reinforced TPO walkpad that provides a safe, stable and maintenance-free walkway for quick and easy access to rooftop equipment in high traffic areas.
JM TPO T-Joint Patch
Flexible, nonreinforced TPO membrane used to cover joints, discs and fasteners on the membrane.
JM TPO Universal Corners
Flexible, nonreinforced, waffle-patterned TPO membrane used around inside and outside corners.
JM TPO Walkpad
Textured, flexible TPO membrane intended for use as walkway material and protection around high-traffic areas. Provides a safe, stable and maintenance-free walkway for quick and easy access to rooftop equipment in high traffic areas.
JM White EPDM Peel and Stick Flashing
Easily forms flashings around corners and penetrations that cannot be properly detailed with TPO membrane.
JM White EPDM Peel and Stick Inside/Outside Corners
Easily forms flashing around corners and penetrations for specific TPO applications.
TPO Square Pipe Boot
A prefabricated, reinforced 60 mil JM TPO, square boot in 2" and 4" (5.08 cm and 10.16 cm) sizes for tube-flashing application. Pipe boots minimize the need for field fabrication.

Adhesives, Cements, Sealants and More

JM All Season Sprayable Bonding Adhesive, Accessories, and Flush
JM All Season Sprayable Bonding Adhesive is an aerosol bonding adhesive that can be used for TPO and EPDM adhered roofing systems and wall flashings. The JM All Season adhesive complies to Low VOC requirements and is a contact adhesive requiring two-sided application. JM All Season Sprayable Bonding Adhesive can also be used as a primer for JM Self Adhered Vapor Barriers.
JM LVOC Membrane Adhesive - TPO and EPDM
JM LVOC Membrane Adhesive is a one-part, low VOC synthetic polymer-based membrane adhesive.
JM Membrane Bonding Adhesive - TPO and EPDM
JM Membrane Bonding Adhesive is used for adhering JM TPO and EPDM membranes to approved substrates.
JM One-Part Liquid Flashing Kit - Single Ply
JM One-Part Liquid Flashing Kit - Single Ply comes with the JM One Part Pourable Sealer combined with the JM PermaFlash scrim which are ideal for creating a uniform, self-terminating liquid flashing system for use with TPO, EPDM, & PVC.
JM One-Part Pourable Sealer
JM One-Part Pourable Sealer is used as a penetration pocket filler.
JM One-Step Foamable Adhesive
JM One-Step Foamable Adhesive is a polyurethane adhesive for attaching insulation/cover boards to the roof deck or other insulation boards.
JM Roofing System Urethane Adhesive - RSUA
JM Roofing System Urethane Adhesive is a two-component polyurethane adhesive.
JM Single Ply LVOC Caulk
Single Ply LVOC Caulk is used to seal flashing terminations, peel and stick products, and exposed edges of JM membrane cement splices.
JM Single Ply Membrane Cleaner - Low VOC
Single Ply Membrane Cleaner is used to remove dirt, asphalt or other contaminants from JM TPO and PVC single ply membranes to ensure a good weld or bond. Can be used prior to applying TPO Membrane Primer for peel and stick applications.
JM Single Ply Membrane Primer - Low VOC
JM Single Ply Membrane Primer (LVOC) is a synthetic polymer-based Primer for JM TPO and EPDM Membrane surfaces.
JM Single Ply Sealing Mastic
Single Ply Sealing Mastic is used to seal JM Single Ply membranes to terminations and other penetrations.
JM TPO 1168 Membrane Adhesive
JM TPO 1168 Membrane Adhesive is used for adhering JM TPO and JM EPDM membranes to approved substrates. Do not use on fleece-backed membranes at any time.
JM TPO LVOC Edge Sealant
TPO LVOC Edge Sealant is used to seal cut edges of JM TPO membranes.
JM TPO Membrane Cleaner
TPO Membrane Cleaner is a one-part solvent cleaner used to remove dirt, asphalt or other contaminants from TPO membranes.
JM TPO Membrane Primer
JM TPO Membrane Primer is a one-part membrane primer used to prepare surface for adhering TPO peel-and-stick products.
JM TPO Pourable Sealer
TPO pourable sealer is used to fill penetration pockets on TPO roofing systems.
JM TPO Water Based Membrane Adhesive
JM TPO Water Based Membrane Adhesive is a polymeric adhesive designed for bonding TPO membranes to approved roofing substrates.
JM Two-Part Pourable Sealer
JM Two-Part Pourable Sealer is a two-part sealant used as a penetration pocket filler.
JM Two-Part Urethane Insulation Adhesive
JM Two-Part UIA is a Two-part cold-application adhesive used to adhere insulation board products to approved roofing substrates, and insulation to insulation.
JM Two-Part Urethane Insulation Adhesive (UIA) Canister
JM Two-Part Urethane Insulation Adhesive (UIA) Canister is a two-component polyurethane adhesive used for attaching fleece-backed membranes to insulation and insulation boards to the roof deck or to other insulation boards.
JM Weathered Membrane Cleaner
JM Weathered Membrane Cleaner cleans the release agent and dirt from JM TPO and JM EPDM membranes.
SA Primer
SA Primer is composed of SBS synthetic rubbers, adhesive enhancing resins and volatile solvents.
SA Primer Low VOC
SA Primer Low VOC is composed of SBS synthetic rubber and adhesive-enhancing resins.

Insulation and Cover Boards

DEXcell Cement Roof Board
DEXcell Cement Roof Board is a cover board that is able to withstand prolonged exposure to moisture and meets FM Class 1 fire barrier requirements.
DEXcell FA Glass Mat Roof Board
DEXcell FA Glass Mat Roof Board is a cover board with a heavy duty coated fiber glass facer. It is moister and mold resistant and meets FM Class 1 fire barrier requirements.
DEXcell Glass-Mat Roof Board
DEXcell Glass-Mat Roof Board is a gypsum cover board that can be used in mechanically fastened single ply systems.
DEXcell® FA VSH Glass Mat Roof Board
DEXcell® FA VSH Glass Mat Roof Board is competitively priced, easier to install and very severe hail strong to withstand the harshest conditions over the long haul.
DensDeck Prime Roof Board
DensDeck Prime Roof Board is a gypsum cover board with an enhanced coated glass mat facer
DensDeck Roof Board
DensDeck Roof Board is a gypsum cover board with a glass mat facer.
DensDeck StormX Prime Roof Board
DensDeck StormX Prime Roof Board contains an enhanced coated glass mat facer and achieves FM's VSH approval in select JM TPO systems.
ENRGY 3 - Flat and Tapered
ENRGY 3® is a closed-cell polyisocyanurate foam core insulation board offering a high R-value to keep your building well insulated from the elements.
ENRGY 3 CGF - Flat and Tapered
ENRGY 3® CGF is a closed-cell polyisocyanurate foam core with an inorganic-coated glass facer on each side. It offers high R-value per inch and achieves a UL Class A approval in select systems.
ENRGY 3 HD
ENRGY 3® HD is a closed cell polyisocyanurate foam technology provides additional insulation value (R-value of 2.5), with lightweight and high density characteristics.
ProtectoR Foam
Dual-Density Polyisocyanurate Composite Board produced with our High-Density ProtectoR® HD cover board and our standard-density Foam (ENRGY® 3 CGF).
ProtectoR HD
ProtectoR® HD is a high-density polyiso cover board that provides excellent resistance against harsh rooftop conditions including hail, wind uplift, puncture and moisture.
RetroPlus Roof Board
RetroPlus™ Roof Board is a high-density, expanded, perlite-based cover board engineered to optimize system performance across all applications.
SECUROCK Cement Roof Board
SECUROCK Cement Roof Board is ideal for liquid applied membrane roof systems. It has superior wind-uplift performance for a wide variety of roof assemblies and excellent fire performance.
SECUROCK Gypsum-Fiber Roof Board
SECUROCK Gypsum-Fiber Roof Board contains a integral water-resistant core and has excellent fire performance.
SECUROCK Ultralight Glass-Mat Roof Board
SECUROCK Ultralight Glass-Mat Roof Board is a gypsum cover board with fiber glass facer and back.
SeparatoR
SeparatoR® provides an economical solution for mechanically fastened single ply membrane recover applications while adding thermal insulation value to your building.
SeparatoR CGF
SeparatoR® CGF is a versatile, ½"-thick cover board solution that is designed for re-cover applications and offers performance and value.

Fasteners and Plates

All Purpose Fasteners
All Purpose Fasteners are #14 case-hardened steel fasteners with a #3 Phillips head. The point is designed for quick installation in new or re-roof applications.
Extra High Load Fasteners and Plates
Extra High Load #21 fasteners, #3 Phillips head and a drill point contain a corrosion-resistant coating and to be used to mechanically attach thermoplastic membranes.
High Load AccuSeam System
The High Load AccuSeam™ System is a premier automated system for mechanically attached seams. The System positions the 23⁄8" (6.03 cm), round, High Load Plate with eye hooks, and installs the High Load Fastener, up to 6" (15.24 cm) in length in a one-step, continuous process. Standard High Load Plates are not compatible with the AccuSeam™ Fastener and Plate System
High Load Fasteners and Plates
High Load Fasteners are a #15 case-hardened steel roof membrane fastener with Galvalume®*-coated steel seam plates. These fasteners can be used in a thermoplastic induction weld system with RhinoPlate®.
JM ENRGY Anchor
ENRGY® Anchor is a lightweight, roof-top integrated, photovoltaic (PV)-mounting solution consisting of a Galvalume®*-coated steel plate welded to a stainless steel stud, with a JM membrane flashing target. Each assembly includes a leveling washer and membrane separator.
JM Purlin Fastener
The JM Purlin Fastener is a steel-coated fastener with a ¼" hex head and ¾" (19 mm) drill point. The drill point allows the fastener to be drilled through the purlin before the threads engage into the standing seam metal roof.
JM RetroDriller Fasteners
JM RetroDriller Fastener is designed for attaching single ply membrane systems to structural purlins (up to 3 /16”) in standing seam metal roof retrofit applications.
JM TPO RhinoPlate
JM TPO RhinoPlate® is a 3" (76.2 mm) round specially coated Galvalume®* plate with a recessed center and raised flat bonding surface. The JM TPO RhinoPlate® is a roof attachment system that uses heat induction technology
JM Termination Systems
JM Termination Systems include termination bars, anchor discs and masonry nail-in anchor and are used for membrane fastening systems.
JM VSH Plate
JM VSH Plates are 2.2" round heavy duty reinforced polymer plates with barbs utilized for in seam single ply membrane securement, and cover board preliminary securement of Very Severe Hail rated single ply membrane systems.
JM isoweld
JM isoweld® is 3.12" (79.2 mm) round G-90 steel plate with a flat bonding surface of proprietary TPO or PVC adhesive coating. Utilizing induction weld technology, JM isoweld® simultaneously fastens the insulation and membrane. Designed to be used with JM #15 Dekfast Fasteners.
Lite-Deck Fasteners and Plates
Lite-Deck Fasteners are available in lengths from 25 /8” to 12" (67 mm to 305 mm), come with a square drive and offer coarse thread to provide high pullout resistance.
Membrane Battens
Membrane Battens are a 1" wide, prepunched, polymer batten strips with prepunched, counter-sunk, GALVALUME®*-coated steel anchor bars.
Polymer Auger Fasteners
Polymer Auger Fasteners are glass-reinforced nylon fasteners with an internal ¼" (6 mm) square drive. Polymer Auger Fasteners have a 1" (2.5 cm) diameter head.
Structural Concrete Deck Fasteners and Plates
The Structural Concrete Deck Fastener is a diamond point, non-threaded carbon steel insulation and membrane fastener.
UltraFast AccuTrac Fastener and Plate System
The UltraFast® AccuTrac™ Fastener and Plate System utilizes the standard UltraFast® Fastener and the UltraFast® Accutrac™, recessed or flat bottomed, square plate. The AccuTrac™ tool positions the plate and installs fasteners 15⁄8" - 6" (4.13 cm - 15.24 cm) in a one-step process. Consistent vertical alignment of fasteners ensures maximum thread engagement and pullout performance.
UltraFast Fasteners and Plates
UltraFast® Fasteners and Plates are used to fasten insulation in both multi-ply and single ply systems. The UltraFast® Fastener is a #12, case-hardened steel, polymer-coated fastener with a buttress thread design that provides maximum pullout values and minimizes fastener backout. The UltraFast® Plates are either round, high strength polypropylene plates with a special locking feature or round or square, premium Galvalume®*-coated steel metal plates.
UltraLok Locking Impact Fastener and Plate
UltraLok™ Locking Impact Fasteners and Plates consist of a preassembled Galvanized steel tube, a 2.7" (6.86 cm) Galvalume®*-coated steel disc, and a precision-formed, coated- steel, high tensile, wirelocking staple. The disc is securely clamped to the tube and is rib-reinforced to resist cupping.

Liquid Applied

JM SP Liquid Flashing Concrete Primer
JM SP Liquid Flashing Concrete Primer is used to prime properly prepared and abraded concrete and masonry substrates that comes into contact with JM single ply membranes as part of the JM SP Liquid Flashing System.
JM SP Liquid Flashing Metal and Wood Primer
JM SP Liquid Flashing Metal and Wood Primer is used to prime properly prepared and acceptable metal and wood substrates that comes into contact with JM single ply membranes as part of the JM SP Liquid Flashing system.
JM SP Liquid Flashing Resin
JM Single Ply Liquid Flashing Resin is a two-part, cold-applied, polyurethane-based product that creates a uniform self-terminating flashing ideal for tying together JM single ply membranes with most common roofng materials.
JM SP Liquid Flashing Scrim
JM SP Liquid Flashing Scrim is a polyester based, nonwoven reinforcement fabric used in the JM SP Liquid Flashing system. The soft, flexible fabric is designed for use around oddly shaped, difficult penetrations and tying together different roofing substrates.
JM SP Liquid Flashing TPO and PVC Primer
JM SP Liquid Flashing TPO and PVC Primer is used to prime the JM TPO and PVC (KEE and SD Plus) single ply membranes as part of the JM SP Liquid Flashing system.

Coatings

JM Coating Acrylic
JM Coating Acrylic is designed for use as a reflective top coat either over built-up, modified bitumen, or mechanically attached or adhered aged TPO or PVC membranes.
JM Coating Acrylic CR
JM Coating Acrylic CR is designed for use as a reflective top coat either over built-up, modified bitumen, or mechanically attached or adhered aged TPO or PVC membranes.
JM Coating Acrylic Flashing
Designed for use over a variety of substrates, JM Coating Acrylic Flashing is a reinforced flashing mastic used for repair applications, or to seal common flashing conditions when using JM Coating Acrylic and JM Coating Acrylic CR.
JM Coating Field Polyester Reinforcing Fabric
JM Coating Field Polyester Reinforcing Fabric is a firm stitch-bond polyester used in JM Coatings systems.
JM Coating Polyester Reinforcing Fabric
JM Coating Field Polyester Reinforcing Fabric is a non-woven, fabric reinforcement.
JM Coating Repair Tape
JM Coating Repair Tape is used to seal seams, flashings and repair areas of existing roof prior to application of JM Coating Membrane systems.
JM Coating Silicone
JM Coating Silicone is designed for use over a variety of substrates, including built-up, modified bitumen, and aged mechanically attached or adhered TPO and EPDM membranes.
JM Coating Silicone Flashing
Designed for use over a variety of substrates, JM Coating Silicone Flashing is a mastic used for repair applications with a reinforcing fabric, or to seal common flashing conditions when using JM Coating Silicone.
JM Coating Single Ply Primer
JM Coating Single Ply Primer is an adhesion promoter for use on aged single ply surfaces prior to application of the JM Acrylic or Silicone Coatings.
TopGard 4000
One-part, acrylic reflective coating (in white or tan) for bituminous and single ply roof systems.
TopGard 5000
One-part, acrylic reflective coating for bituminous or single ply roof systems.
TopGard Base Coat

One-part, acrylic base coating (for TopGard® 4000 or 5000) that acts as an oil-bleed barrier for bituminous systems.

Specialty Roofing Products

Expansion Joint Cover - PVC EJ/WC
Expand-O-Flash® Style PVC EJ/WC is an expansion joint with reinforced PVC cover to weld the joint assembly to the PVC membrane.
Expansion Joint Cover - Style CF - Curb to Curb
Elastomeric bellows supported by a closed-cell foam backer for installation on wood curbs.
Expansion Joint Cover - Style CF/EJ - Curb to Wall
Elastomeric membrane bellows supported by a closed cell foam backer.
Expansion Joint Cover - Style EJ - Cant to Cant
Elastomeric membrane bellows for installation on roof-to-roof conditions.
Expansion Joint Cover - Style EJ - Cant to Wall
Elastomeric membrane bellows for installation on roof-to-wall installations.
Expansion Joint Cover - Style EJ/WC - Curb to Curb
Elastomeric or PVC membrane supported by a closed-cell foam backer.
Expansion Joint Cover - Style EJ/WC - Curb to Wall
Elastomeric or PVC membrane for installation on any width curb.
Expansion Joint Cover - TPO EJ/WC
Expand-O-Flash® expansion joint covers are flexible, weather-proof exterior covers for expansion joint openings and are an effective, flexible closure for a wide variety of standard and special applications.
Heavy-Duty TPO RetroDrain
One-piece spun aluminum body, TPO-coated flange and depressed sump area used to replace existing drains in re-roofing applications.
Hercules RetroDrain
One-piece spun aluminum body, heavy-duty cast aluminum dome/clamping ring and depressed sump area and is designed for use in all roofing systems.
OverFlow and FlowControl
Spun aluminum round drain attachment for use with all RetroDrains.
PVC AlumaWeld RetroDrain
AlumaWeld® RetroDrain® is a one-piece spun aluminum body, plastisol-coated flange and depressed sump area used in PVC roof systems to replace existing drains in re-roofing applications.
Presto Lock Coping System
A cost-effective snap-on coping system designed for use with single ply, built-up and modified bitumen roofing systems. The system consists of galvanized steel anchor clips and aluminum or galvanized coping covers in a variety of thicknesses and colors.
Presto-Tite Edge One Fascia System
Edge One Fascia system offers convenience and economical pricing to simplify projects and maximize profits. Our Edge One Fascia for single-ply roofs helps to protect the roof system against high wind events, saving the building from costly damage. The design eliminates the stripping in typical of other products, making Edge One Fascia fast and easy to install.
Presto-Tite Fascia System (Bituminous Systems)
A high performance edge treatment for all modified bitumen and BUR roof projects. Nonpenetrating design allows for vertical face attachment without penetrating the horizontal flange, and eliminates the need to strip-in the deck flange, eliminating potential delamination between the asphalt and metal deck flange due to thermal expansion and contraction forces. Provides maximum protection against wind uplift damage.
Presto-Tite Fascia System (Single Ply Systems)
A high performance edge treatment for fully adhered or mechanically fastened single ply roof projects. Nonpenetrating design allows for vertical face attachment without penetrating the horizontal flange, and eliminates the need to strip-in the deck flange, eliminating potential delamination between the adhesive and metal deck flange due to thermal expansion and contraction forces. Provides maximum protection against wind uplift damage.
Presto-Weld Drip Edge
Presto-Weld drip edge is a factory-fabricated coated metal edge system used to terminate at the perimeter of a PVC or TPO membrane. This edge comes with a factory applied, 8" wide PVC flashing strip or 6" wide TPO flashing strip of Johns Manville membrane to help save labor installation costs in the field. Presto-Weld is an economical solution for many conditions such as continuous edge drainage with or without a gutter condition.
U-Flow Screwdriver
The U-Flow Screwdriver is an extra long screwdriver to tighten the special recessed head screws on U-Flow compression seals.
Vertical Expansion Joint Cover
Elastomeric membrane bellows and 4" metal flanges for use with vertical expansion joints.

Use our locator to find your nearest contractor or distributor.

Find Your Local Roofing Contractor or Distributor Here

TPO Installation and Details

When it comes to design, we've got the tools to get you from the desk to the roof. Here you will find all of the TPO specifications, 3-part specs, details and installation guides. If you have any questions when it comes to installation, please contact our Specifier Services Group for design and your local technical representative for the field.

Flashing Details
Fastening Patterns
Assembly Plates
Specifications
Installation Guides

TPO MASTER DETAILS	CAD	PDF	BIM
T-FW-M1 TPO Base & Wall Flashing with Coping Master Detail	DWG	PDF	-
T-FW-M1I TPO Base & Wall Flashing with Coping Isometric View Master Detail	DWG	PDF	-
T-FW-M2I Highwall Flashing with Metal Backing Strip Isometric View Master Detail	DWG	PDF	-
T-FW-M3I TPO Self Adhered Base & Wall Flashing with Coping Isometric View	DWG	PDF	-
T-FW-M4I TPO Base and Wall Flashing with Coping ISO View	DWG	PDF	-
T-FW-M5I TPO RhinoBond Wall Flashing ISOmetric View	DWG	PDF	-
T-FW-M6I TPO Rhinobond Wall Flashing ISO Metric View	DWG	PDF	-
T-FW-M7I TPO Base and Wall Flashing 10 FT Max with Coping	DWG	PDF	-

*BASE TIE-IN DETAILS*	*CAD*	*PDF*	*BIM*
T-FW-B1 Base Flashing with Horizontal Reinforced Termination Strip - RTS	DWG	PDF	RVT
T-FW-B2 Base Flashing with Vertical Reinforced Termination Strip - RTS	DWG	PDF	-
T-FW-B3 Base Tie-In Fastener & Plate	DWG	PDF	RVT
T-FW-B4 Base Tie-In Fastener & Plate on Wall	DWG	PDF	-
T-FW-B5 Membrane Flashing Base Tie-In - High Internal Pressure	DWG	PDF	RVT
T-FW-B6 Base Tie-In - RhinoPlate System	DWG	PDF	-
T-FW-B7 Base Tie-in Knee Wall Brace 2/12 Slope	DWG	PDF	-
T-FW-B8 Base Tie-In (Loose Hung Flashing)	DWG	PDF	-
T-FW-B9 TPO Self Adhered Base Tie-In (Fastener & Plate)	DWG	PDF	-
T-FW-B10 TPO Self Adhered Base Tie-In (Fastener & Plate) On Wall	DWG	PDF	-
T-FW-B11 TPO Self Adhered Membrane Flashing Base Tie-In (High Internal Pressure)	DWG	PDF	-
T-FW-B12 TPO Self Adhered Base Tie-In (Fastener & Plate) with TPO Cover Strip	DWG	PDF	-
T-FW-B13 Base Tie-In Fleece Backed TPO in RSUA	DWG	PDF	-
T-FW-B13I TPO Fleece backed in RSUA Base and Wall Flashing	DWG	PDF	-
T-FW-B14 Base Tie-In Fleece Backed TPO in Two Part UIA Spatter	DWG	PDF	-
T-FW-B14I TPO Fleece Backed Base and Wall in Two Part UIA Spatter	DWG	PDF	-
T-FW-B15 TPO Base Flashing with Cant Strip	DWG	PDF	-
T-FW-B16 TPO Coated Metal Base Tie-In with Break	DWG	PDF	-
T-FW-B17 Spliced TPO Coated Metal Base Tie-In with Break	DWG	PDF	-
T-FW-B18 TPO Coated Metal Right Angle Base Tie-In	DWG	PDF	-
T-FW-B19 Spliced TPO Coated Metal Right Angle Base Tie-In	DWG	PDF	-

INTERMEDIATE TERMINATION DETAILS	CAD	PDF	BIM
T-FW-I1 TPO Intermediate Membrane Attachment with Fastener & Plate	DWG	PDF	-
T-FW-I2 TPO Cover Strip Wall Flashing Attachment with Fastener & Plate	DWG	PDF	-
T-FW-I3 TPO Intermediate Attachment with Termination Bar	DWG	PDF	-
T-FW-I4 Termination Bar Attachment With Welded TPO Cover Strip	DWG	PDF	-
T-FW-I5 Continuous Flashing Attachment- Termination Bar	DWG	PDF	-
T-FW-I6 Split Flashing Attachment – Termination Bar	DWG	PDF	RVT
T-FW-I7 TPO Intermediate Termination with Counterflashing & Cut-In Reglet	DWG	PDF	RVT
T-FW-I8 TPO Intermediate Termination with Surface Mounted Counterflashing	DWG	PDF	RVT
T-FW-I9 TPO Intermediate Termination with Through-Wall Counterflashing	DWG	PDF	-
T-FW-I10 TPO Intermediate Termination with Termination Bar	DWG	PDF	-
T-FW-I11 TPO Intermediate Termination Below Wall Cladding	DWG	PDF	RVT
T-FW-I12 TPO Intermediate Membrane Attachment w/Termination Bar	DWG	PDF	-
T-FW-I13 TPO Intermediate Termination (Loose Hung Flashing)	DWG	PDF	-

TOP OF WALL DETAILS	CAD	PDF	*BIM*
T-FW- T1 Fabricated Metal Coping Over Adhered TPO	DWG	PDF	RVT
T-FW- T2 Presto Lock Coping System Over TPO	DWG	PDF	-
T-FW- T3 Presto-Tite Fascia System On Sloped Parapet	DWG	PDF	-
T-FW- T4 Perma-Tite Continuous Cleat Coping System Over TPO	DWG	PDF	-
T-FW- T5 Top of Wall Termination with Stone Coping	DWG	PDF	-

TPO MEMBRANE SEAMING DETAILS	CAD	PDF	BIM
T-MS-01 Cut Edge Sealant	DWG	PDF	-
T-MS-02 In-Lap Fastening Method-Steel Deck	DWG	PDF	-
T-MS-03 In-Lap Fastening Method-Plywood Deck	DWG	PDF	-
T-MS-04 In-Lap Fastening Method-Concrete Deck	DWG	PDF	-
T-MS-05 In-Lap Fastening Method-Wood Plank Deck	DWG	PDF	-
T-MS-06 Continuous Strip Fastening Method	DWG	PDF	-
T-MS-07 Membrane Side Lap	DWG	PDF	-
T-MS-08 TPO Fleece Backed Adhesive Applied Membrane Butted End Lap	DWG	PDF	-
T-MS-09 Slope Transition-Valley	DWG	PDF	-
T-MS-10 Slope Transition-Ridge	DWG	PDF	-
T-MS-11 TPO Self Adhered Membrane Butted End Lap	DWG	PDF	-
T-MS-12 TPO T-Joint Patch	DWG	PDF	-
T-MS-13 Headlap Over Field Seam with T-Joint Patch	DWG	PDF	-

TPO FLASHING CURB & CORNER DETAILS	CAD	PDF	BIM
T-FC-01 Prefabricated Metal Curb Base Flashing	DWG	PDF	RVT
T-FC-02 Roof Hatch	DWG	PDF	-
T-FC-03 Outside Corner	DWG	PDF	-
T-FC-04 Inside Corner	DWG	PDF	-
T-FC-05 TPO Wood Curb Base Flashing	DWG	PDF	-
T-FC-06 TPO Flashing Wall with Term Bar and Corner Coping	DWG	PDF	-
T-FC-07 Membrane Attachment Outside Corner	DWG	PDF	-
T-FC-08 Membrane Attachment Inside Corner	DWG	PDF	-
T-FC-09 Outside Corner with TPO Coated Metal with Break	DWG	PDF	-
T-FC-10 Outside Corner with TPO Coated Metal	DWG	PDF	-
T-FC-11 Inside Corner with TPO Coated Metal with Break	DWG	PDF	-
T-FC-12 Inside Corner with TPO Coated Metal	DWG	PDF	-
T-FC-13 RTU Curb Flashing with Metal Counter Flashing	DWG	PDF	-
T-FC-14 RTU Curb Flashing with Substrate Mounted Flange	DWG	PDF	-

*TPO PROTECTION DETAILS*	*CAD*	*PDF*	*BIM*
T-PT-01 Support-Light	DWG	PDF	-
T-PT-02 Support-Medium	DWG	PDF	-
T-PT-03 Support-Heavy	DWG	PDF	-
T-PT-04 Walkway-Concrete Paver	DWG	PDF	-
T-PT-05 TPO Walkpads Over Adhered TPO Membrane	DWG	PDF	RVT
T-PT-06 TPO Walkpad Fleece Backed System Fully Adhered	DWG	PDF	-
T-PT-07 TPO Walkpad Over Mechanically Fastened TPO Membrane	DWG	PDF	-
T-PT-08 Lightning Rod-Wall Mount	DWG	PDF	-
T-PT-09 Lightning Rod-Roof Mount	DWG	PDF	-
T-PT-10 Grease Trap	DWG	PDF	-
T-PT-11 JM Single Ply Safety Strip Over TPO Membrane	DWG	PDF	-
T-PT-12 JM ENRGY Anchor - TPO	DWG	PDF	-
T-PT-13 Hurricane Peel Stop Anchor Bar	DWG	PDF	-

TPO COVER TAPE DETAILS	CAD	PDF	BIM
T-FE-C1 Metal Drip Edge with TPO Cover Tape	DWG	PDF	RVT
T-FE-C2 Gravel Stop with TPO Cover Tape	DWG	PDF	RVT
T-FE-C3 Gutter & Metal Edge with TPO Cover Tape	DWG	PDF	RVT


*TPO Heat Weldable Cover Tape Details*	*CAD*	*PDF*	*BIM*
T-FE-C4 Metal Drip Edge with JM TPO Heat Weldable Cover Tape	DWG	PDF	-
T-FE-C4I Metal Drip Edge with JM TPO Heat Weldable Cover Tape	DWG	PDF	-

*TPO COATED METAL DETAILS*	*CAD*	*PDF*	*BIM*
T-FE-CM1 Drip Edge-TPO Coated Metal	DWG	PDF	-
T-FE-CM2 Drip Edge-TPO Coated Metal Adhered Membrane Only	DWG	PDF	-
T-FE-CM3 Gravel Stop-TPO Coated Metal	DWG	PDF	-
T-FE-CM4 Gravel Stop-TPO Coated Metal Adhered Membrane Only	DWG	PDF	-
T-FE-CM5 Gutter & TPO Coated Metal Edge	DWG	PDF	RVT
T-FE-CM6 Butt Joint At Edge-TPO Coated Metal	DWG	PDF	-

*PRE-MANUFACTURED (METAL) DETAILS*	*CAD*	*PDF*	*BIM*
T-FE-P1 JM Presto Tite Drip Edge	DWG	PDF	-
T-FE-P2 JM Presto-Tite Fascia System For Single Ply Systems	DWG	PDF	-
T-FE-P3 JM Presto Tite Edge One	DWG	PDF	-
T-FE-P4 JM Perma-Tite System 200 Fascia	DWG	PDF	-
T-FE-P5 JM Metal Drip Edge With TPO Cover Tape	DWG	PDF	-
T-FE-P6 JM Gravel Stop With TPO Cover Tape	DWG	PDF	-
T-FE-P7 JMTPO Presto Weld Drip Edge	DWG	PDF	-
T-FE-P8 Extended JM Presto Tile Fascia	DWG	PDF	-

*TPO DRAINS & VENTS DETAILS*	*CAD*	*PDF*	*BIM*
T-DV-01 Vent Pipe	DWG	PDF	RVT
T-DV-02 Vent Pipe-Hot	DWG	PDF	RVT
T-DV-03 Through-wall Scupper	DWG	PDF	RVT
T-DV-03I Through-wall Scupper	DWG	PDF	RVT
T-DV-04 Primary Scupper With Tapered Insulation Sump	DWG	PDF	RVT
T-DV-05 Low-Wall Primary Scupper Flashing	DWG	PDF	RVT
T-DV-06 Overflow Scupper	DWG	PDF	RVT
T-DV-07 Primary Drain Sump-Low Slope-Up To 3:12 Slope	DWG	PDF	RVT
T-DV-08 Primary Drain Sump-Steep Slope-Greater Than 3:12 Slope	DWG	PDF	-
T-DV-09 Primary Drain Sump-Fleece Backed Membrane	DWG	PDF	-
T-DV-09I TPO Fleece Backed Adhesive Applied Primary Drain In Sump	DWG	PDF	-
T-DV-10 JM Heavy Duty TPO Retro Drain	DWG	PDF	RVT
T-DV-11 Primary Drain Sump-Mechanically Fastened Membrane	DWG	PDF	RVT
T-DV-12 Primary and Overflow Drain Sump	DWG	PDF	-
T-DV-13 JM TPO Hercules Retrodrain	DWG	PDF	-
T-DV-14 Roof Drain	DWG	PDF	-
T-DV-15 Overflow Roof Drain with Water Dam	DWG	PDF	-
T-DV-16 Primary Roof Drain Insert 6:12 Slope	DWG	PDF	-
T-DV-17 Primary and Overflow Roof Drain	DWG	PDF	-

TPO FLASHING PENETRATION DETAILS	CAD	PDF	BIM
T-FP-01 TPO Pipe Boot	DWG	PDF	RVT
T-FP-02 JM TPO 2 Piece Penetration Pocket	DWG	PDF	RVT
T-FP-03 TPO-Coated Metal Penetration Pocket	DWG	PDF	-
T-FP-04 TPO Split Pipe Boot-Round	DWG	PDF	RVT
T-FP-05 TPO Split Pipe Boot-Square	DWG	PDF	RVT
T-FP-06 TPO Split Pipe Boot-Square-Clamped	DWG	PDF	-
T-FP-07 Field Fabricated Pipe Penetration	DWG	PDF	RVT
T-FP-08 TPO Peel and Stick Pipe Boot	DWG	PDF	-
T-FP-09 Multi-Pipe with TPO Coated Metal Penetration Pocket	DWG	PDF	-
T-FP-10 Multi-Pipe with Fabricated Metal Penetration Pocket	DWG	PDF	-

*TPO TIE-IN FLASHING DETAILS*	*CAD*	*PDF*	*BIM*
T-TI-01 Transition For Staged Roofing With TPO Coated Metal	DWG	PDF	-
T-TI-02 Transition To Shingle Roof With TPO Coated Metal	DWG	PDF	-
T-TI-03 Curb Tie-In To Roof By Others	DWG	PDF	RVT

*TPO EXPANSION JOINT DETAILS*	*CAD*	*PDF*	*BIM*
T-EJ-01 Expansion Joint-Roof To Wall	DWG	PDF	RVT
T-EJ-02 Expansion Joint-Roof To Roof	DWG	PDF	RVT
T-EJ-03 Expand-O-Flash Roof To Roof Expansion Joint Cover-Style EJ	DWG	PDF	-
T-EJ-04 Expand-O-Flash Roof To Wall-Style EJ	DWG	PDF	-
T-EJ-05 Expand-O-Flash Curb To Curb Expansion Joint Cover-Style CF	DWG	PDF	-
T-EJ-06 Expand-O-Flash Curb To Wall Expansion Joint Cover-Style CF/EJ	DWG	PDF	-
T-EJ-07 Expand-O-Flash Curb to Wall (Style TPO EJ-WC)	DWG	PDF	-
T-EJ-08 Expand-O-Flash Curb to Curb (Style PVC EJ-WC)	DWG	PDF	-
T-EJ-09 Expand-O-Flash Curb to Wall Expansion Joint Cover-Style CF/EJ	DWG	PDF	-
T-EJ-10 Expand-O-Flash Curb Expansion Joint Cover	DWG	PDF	-

*TPO with White EPDM Flashing Details*	*CAD*	*PDF*	*BIM*
TWE-DV-02 - TPO Vent Stack (Hot) with JM White EPDM	DWG	PDF	-
TWE-DV-03 - Through-Wall Scupper with JM White EPDM	DWG	PDF	-
TWE-DV-06 - Overflow Scupper with JM White EPDM	DWG	PDF	-
TWE-FC-03 - TPO Outside Corner with JM White EPDM	DWG	PDF	-
TWE-FC-04 - TPO Inside Corner with JM White EPDM	DWG	PDF	-
TWE-FP-04 - TPO Field Fabricated Pipe Wrap with JM White EPDM	DWG	PDF	-
TWE-FW-01 - TPO End Wall Transistion with JM White EPDM	DWG	PDF	-

*VARIOUS (MISCELLANEOUS) DETAILS*	*CAD*	*PDF*	*BIM*
T-FE-V1 Wood Nailer Attachement	DWG	PDF	-
T-FE-V2 Gutter & Termination Bar	DWG	PDF	-
T-FE-V3 RhinoPlate-Standing Seam Retro-Fit Purlin Attachment	DWG	PDF	-
T-FE-V4 RhinoPlate-Standing Seam Retro-Fit Gravel Stop	DWG	PDF	-
T-FE-V5 RhinoPlate-Standing Seam Retro-Fit Gutter	DWG	PDF	-
T-FE-V6 Gutter and JM Drain Bar	DWG	PDF	-


SINGLE PLY LIQUID FLASHING CURB AND CORNER DETAIL	*CAD*	DWG	*BIM*
SPL-FC-01 Typical TPO or PVC Door Sill Flashing	PDF	DWG	-


*SINGLE PLY LIQUID FLASHING DRAINS AND VENTS DETAILS*	CAD	PDF	BIM
SPL-DV-01 Throughwall Metal Scupper with TPO or PVC Membrane	DWG	PDF	-


SINGLE PLY LIQUID FLASHING PENETRATION DETAILS	CAD	PDF	BIM
SPL-FP-01 TPO or PVC Roof Multi-Pipe Penetration Flashing	DWG	PDF	-
SPL-FP-03 TPO or PVC Square Tube Penetration Flashing	DWG	PDF	-
SPL-FP-05 TPO or PVC Wide Flange Penetration Flashing	DWG	PDF	-
SPL-FP-07 Wide Flange Flashing Scrim Layout	DWG	PDF	-
SPL-FP-08 TPO or PVC Angle Iron Penetration Flashing	DWG	PDF	-
SPL-FP-10 Angle Iron Flashing Scrim Layout	DWG	PDF	-

*SINGLE PLY LIQUID FLASHING WALL DETAIL*	*CAD*	PDF	*BIM*
SPL-FW-01 Wall Mounted Ladder TPO or PVC Base Flashing	DWG	PDF	-
SPL-FW-03 Deck Mounted Ladder TPO or PVC Base Flashing	DWG	PDF	-
SPL-FW-05 Flashing Wall Optional Terminations	DWG	PDF	-

*SINGLE PLY LIQUID FLASHING EXPANSION JOINTS DETAILS*	*CAD*	PDF	*BIM*
SPL-EJ-01 Expansion Joint TPO or PVC Roof to Wall	DWG	PDF	-

*SINGLE PLY ONE-PART POURABLE SEALER DETAILS*	*CAD*	*PDF*	*BIM*
T1P-FP-01 TPO Multi-Pipe Penetration 1-Part Pourable Sealer Liquid Flashing	DWG	PDF	-
T1P-FP-02 TPO Square Tube Penetration 1-Part Pourable Sealer Liquid Flashing	DWG	PDF	-
T1P-FP-03 TPO Wide Flange Penetration 1-Part Pourable Sealer Liquid Flashing	DWG	PDF	-
T1P-FP-04 Wide Flange Flashing Scrim Layout 1-Part Pourable Sealer Liquid Flashing	DWG	PDF	-
T1P-FP-05 TPO Angle Iron Penetration Flashing 1-Part Pourable Sealer Liquid Flashing	DWG	PDF	-
T1P-FP-06 Angle Iron Flashing Scrim Layout 1-Part Pourable Sealer Liquid Flashing	DWG	PDF	-

TPO SELF-ADHERED FLASHING DETAILS	CAD	PDF	BIM
T-FW-B9 TPO Self-Adhered Base Tie-In (Fastener & Plate)	DWG	PDF	-
T-FW-B10 TPO Self-Adhered Base Tie-In (Fastener & Plate) on Wall	DWG	PDF	-
T-FW-B11 TPO Self-Adhered Membrane Flashing Base Tie-In (High Internal Pressure)	DWG	PDF	-
T-FW-B12 TPO Self-Adhered Base Tie-In (Fastener & Plate) with TPO Cover Strip	DWG	PDF	-
T-FW-M3I Self-Adhered TPO Base & Wall Flashing with Coping ISO View	DWG	PDF	-
T-FW-M8I TPO Self-Adhered Continuous Wall Flashing	DWG	PDF	-
T-MS-11 TPO Self-Adhered Membrane Butted End Lap	DWG	PDF	-

*TPO BITUMINOUS HYBRID DETAILS*	*CAD*	*PDF*	*BIM*
TH-FW-B1 Base Tie In With Term Bar	DWG	PDF	-
TH-FW-B2 Base Tie In (Fastener & Plate) with Cant	DWG	PDF	-
TH-FW-B3 Base Tie In (Fastener & Plate) On Wall	DWG	PDF	-
TH-FW-B4 Base Tie In With Term Bar	DWG	PDF	-
TH-FW-M1 TPO Hybrid Base & Wall Flashing with Coping	DWG	PDF	-
TH-FW-M1I TPO Hybrid Base & Wall Flashing with Coping Isometric View	DWG	PDF	-
TH-FW-M2I Highwall Flashing with Metal Backing Strip Isometric View	DWG	PDF	-
TH-MS-01 TPO Fleece Backed Membrane Butted End Lap	DWG	PDF	-
TH-FC-01 Prefabricated Metal Curb Base Flashing with Cant	DWG	PDF	-
TH-FC-02 Prefabricated Metal Curb Base Flashing	DWG	PDF	-
TH-FE-CM1 Drip Edge (TPO Coated Metal)	DWG	PDF	-
TH-FE-CM2 Gravel Stop (TPO Coated Metal)	DWG	PDF	-
TH-FE-CM3 Gutter & TPO Coated Metal Edge	DWG	PDF	-
TH-FE-P1 JM Presto-TIte Edge One Fascia System	DWG	PDF	-
TH-FE-P2 Presto Tite Fascia System	DWG	PDF	-
TH-DV-01 Field Fabricated Vent Pipe	DWG	PDF	-
TH-DV-02 Drain Detail	DWG	PDF	-
TH-DV-03 Vent Pipe	DWG	PDF	-
TH-FP-01 Pipe Boot	DWG	PDF	-

VAPOR BARRIER SA DETAILS	CAD	PDF	*BIM*
VB-1 JM Vapor Barrier SA - Wall Base Detail	DWG	PDF	-
VB-1 (ALT) JM Vapor Barrier SA - Wall Base Detail - Alt	DWG	PDF	-
VB-2 JM Vapor Barrier SA - Pipe Penetration Detail	DWG	PDF	-
VB-3 JM Vapor Barrier SA - Drain Detail	DWG	PDF	-
VB-4 JM Vapor Barrier SA - Detail at Field Laps	DWG	PDF	-
VB-5 JM Vapor Barrier SA - Outside Curb Detail	DWG	PDF	-
VB-6 JM Vapor Barrier SA - Inside Curb Detail	DWG	PDF	-

*VAPOR BARRIER SAR DETAILS*	CAD	PDF	*BIM*
VB-1 JM Vapor Barrier SAR - Wall Base	DWG	PDF	-
VB-1 (ALT) JM Vapor Barrier SAR - Wall Base	DWG	PDF	-
VB-2 JM Vapor Barrier SAR - Pipe Penetration	DWG	PDF	-
VB-3 JM Vapor Barrier SAR - Drain	DWG	PDF	-
VB-4 JM Vapor Barrier SAR - Field Laps	DWG	PDF	-
VB-5 JM Vapor Barrier SAR - Outside Curb	DWG	PDF	-
VB-6 JM Vapor Barrier SAR - Inside Curb	DWG	PDF	-

2x4 Ft. Roof Insulation Fastener Placement - Mechanically Fastened, Adhered

4x4 Ft. Roof Insulation Fastener Placemen t - Mechanically Fastened, Adhered

4x8 Ft. Roof Insulation Fastener Placemen t - Mechanically Fastened, Adhered

JM TPO RhinoPlate Fastening System 6-10-15

JM TPO RhinoPlate Fastening System 8-15-20

T-RSPR-1 RhinoPlate® Fastened TPO Membrane to Purlins

T-RSPR-2 RhinoPlate® Fastened TPO Membrane - Edge Flashings – Gravel Stop

T-RSPR-3 RhinoPlate® Fastened TPO Membrane - Edge Flashings – Gutter

TM-12 Full Mechanically Fastened JM TPO (12" O.C.)

TM-12 Mechanically Fastened JM TPO (12" O.C.)

TM-18 Mechanically Fastened JM TPO (18" O.C.)

TM-6 Full Mechanically Fastened JM TPO (6" O.C.)

TM-6 Mechanically Fastened JM TPO (6" O.C.)

TMR-12 10" RPS and Mechanically Fastened JM TPO (12" O.C.)

TMR-6 10" RPS and Mechanically Fastened JM TPO (6" O.C.)

TUA-4-4-4 TPO-FB Urethane Adhesive

TUA-6-4-4 TPO-FB Urethane Adhesive

TUA-12-6-4 TPO-FB Urethane Adhesive

CBUA-12-6-4 Cover Board Urethane Adhesive

ICBUA-8-4-4 Insulation and Cover Board Urethane Adhesive

ICBUA-12-6-4 Insulation and Cover Board Urethane Adhesive

INUA-12-6-4 Insulation Urethane Adhesive

Assembly Plate Use Instructions

*Please be sure to download the file before selecting your assembly.*

TPO Adhered Assembly Plate

TPO Mechanically Attached Assembly Plate

TPO Self-Adhered Assembly Plate

Download the 3-Part TPO Master Spec

Installation Guides

JM TPO Application Guide

JM TPO Application Guide (Section 2 Only) - Español

JM Vapor Barrier Installation Guide

JM Vapor Barrier Installation Guide - Español

RhinoPlate Installation Guide

RhinoPlate Installation Guide - Español

JM SP Liquid Flashing Installation Guide

JM SP Liquid Flashing Installation Guide - Español

JM All Season Sprayable Bonding Adhesive Installation Guide

JM All Season Sprayable Bonding Adhesive Installation Guide - Español

JM Two-Part UIA Adhesive - Canister

Additional Resources

TPO Membrane Selector Guide

TPO Membrane Selector Guide - Español

Adhesives and Cements Selector Guide

Insulation and Cover Board Selector Guide

Fasteners and Plates Selector Guide

Insulation and Cover Board Selector Guide - Español

Documents

Videos

TPO Installation and Product Features

Product Feature

JM TPO

Hear more about what it means to JM on what it takes to make an exceptional TPO product.

Watch Here
Product Feature

JM TPO Quality is Preferred by Top Contractors

We sat down with a few of our top contractors and learned how much the quality of JM TPO matters to getting the job done right.

Watch Here
Product Feature

JM TPO Self-Adhered

Check out how the benefits of using a JM TPO self-adhered membrane on your next project..

Watch Here
Product Feature

JM TPO Self-Adhered vs Adhered Systems

Watch our time-lapse as we have contractors install both our JM TPO self-adhered membrane vs. using a traditional adhered TPO system.

Watch Here
Product Feature

JM TPO Rhinobond in Action

Check out how Great Lakes Roofing uses the JM 60 mil TPO Rhinobond Systems with a 20 Year NDL..

Watch Here
Installation

TPO Curb Flashing

Learn how to properly install JM TPO outside corners.

Watch Here
Installation

JM TPO Penetration Pocket Base Attachment

Learn how to properly install a TPO penetration pocket base attachment.

Watch Here
Installation

TPO Inside Corner

This installation videos covers how to install an inside corner using Johns Manville TPO.

Watch Here
Installation

JM TPO Inside Corner Flashing

Learn how to use a "pig ear" method of installation on your TPO insides corner flashing.

Watch Here
Installation

TPO Field Seams

This installation video shows how to get a proper field seam using Johns Manville TPO.

Watch Here
Installation

TPO RTS & Wall Flashing

This installation video covers how to properly install a TPO reinforced termination strip, and then install a wall flashing using Johns Manville TPO.

Watch Here
Installation

TPO Penetration Pocket

Learn how to properly install JM TPO penetration pockets.

Watch Here

Vídeos de instalación de TPO

Instalación de TPO

Cavidad de Penetración de TPO

Mira Aquí
Instalación de TPO

Esquina Interior de TPO

Mira Aquí
Instalación de TPO

Uniones de Campo de TPO

Mira Aquí
Instalación de TPO

Sistema RhinoBond Para TPO

Mira Aquí
Instalación de TPO

Tira de Terminación Reforzada de TPO y Membrana de Pared

Mira Aquí
Instalación de TPO

Tapajuntas de TPO Para Bordillos

Mira Aquí

TPO Project Spotlight

Project Sugar

ProtectoR HD Plays a Key Roll in New Construction

Against the backdrop of the Rocky Mountains’ Front Range, commercial real estate developer Trammell Crow Company (TCC) transformed 70 acres of farmland into an industrial park. All new infrastructure—roads, electricity, water, sewage—was put into place before a massive 818,300 square foot roofing project was constructed.

Watch Here
Barber and Associates

JM and Barber and Associates Skillfully Navigate Supply Chain to Complete Job

With today's current economic status, supply chain is a common issue across the country. For this 23 acre job in Florida, Johns Manville and Barber and Associates worked together to defy supply chain issues to meet the project deadline.

Watch Here
Great Lakes Roofing

New JM TPO 12 Foot Rolls Lead to an Increase in Productivity

The site of a nearly 170,000 square foot former Menards home improvement store was refurbished and reconfigured to house a host of retailers including: movie theaters, an indoor skydiving venue, a Planet Fitness gym and many others. Located near the Chicagoland Territory, the reroofing was completed in September 2018.

Watch Here
Tradepoint St. John's

Largest Building in Maryland Roofed by Johns Manville

The former Bethlehem Steel manufacturing site at Tradepoint St. John’s is getting new life in a modern building as a distribution center for a clothing manufacturer. Proximity to rail, land and water makes this location ideal for global companies to expedite both their shipping and receiving operations.

Learn More

Roofing Institute Contractor Training

Our JM approved contractors can take advantage of hands-on training and learn all the latest best practices for your profession through our learning program. As low-slope roof technology, materials and performance demands evolve, it is crucial to understand new materials and technologies. JM has built an education and development initiative that utilizes our over 160 years of experience in commercial roofing.

Training mechanically fastening TPO around a penetration.

BURSI for Design Professionals

Our BURSI® program, run by our Specifier Services Team offers customizable education programs that are certified by American Institute of Architects (AIA). We offer anything from one-hour “Lunch and Learns” to a 10-hour, multiple-day seminar. Our program is known as (BURSI) Better Understanding of Roofing Systems Institute. Please contact your local sales representative for more information on upcoming BURSI dates or visit our calendar to see the next educational seminar is in your area.

Roofing Systems Blog

Commercial Roofing

Get the Job Done Faster with JM’s New EPDM FIT SA (Even in the Cold)

At Johns Manville, we know time matters when it comes to a roofing job going right. So, too, do temperatures. Our new JM EPDM FIT SA allows contractors to make the most of bo...

Read this article
Commercial Roofing

Johns Manville Roofing Volunteer Day

A team of 21 Johns Manville Roofing Systems employees recently spent a morning pitching in at Food Bank of the Rockies as part of the company-wide Global Community Day. No...

Read this article
Commercial Roofing

Johns Manville Rocks the Trade Show Scene

There’s nothing like a crowded show floor to ramp up excitement about the roofing industry. At least that’s how we see it at Johns Manville. Attending educational events and ...

Read this article
Commercial Roofing

JM TPO Heat Weldable Cover Tape Joins JM Lineup

At Johns Manville, we know versatile products can be the key to a roofing project not only coming in on time and on budget, but also standing the test of time. That’s why we’...

Read this article
Commercial Roofing

Above It All Episode 45: Johns Manville Introduces EPDM FIT Self-Adhered

Podcast episode 45 features Johns Manville's new EPDM Product Manager, Kevin Roepe. Kevin discusses Johns Manville's new EPDM FIT Self-Adhered membrane, product highlights, a...

Read this article
Commercial Roofing

Above It All Episode 44: IIBEC Features JM's Technical Sales Experts

Podcast episode 44 features Johns Manville's Technical Sales duo, Rick Gustin and Rob Hughes. Rick and Rob discuss their wind convergence presentation at IIBEC's Internationa...

Read this article
Commercial Roofing

Bright Future Ahead: JM Joins SkillsUSA in Developing Next Generation of Workers

For more than 160 years, people have been at the core of everything Johns Manville does. Recently that commitment took center stage in Georgia, where JM joined forces with th...

Read this article
Commercial Roofing

ENRGY 3® HD Removes Limitations From Reroof of Nonprofit Serving Those with Limited Vision

Limited roof access didn’t stand in the way of finding an affordable reroof for The Lighthouse of Houston, a nonprofit that has serving those with limited vision for more tha...

Read this article
Commercial Roofing

Future of Trades Looks Bright at Let’s Build Camp

JM team members got hands-on last month to help girls build construction skills and help the industry build a pipeline of future professionals at Let’s Build Construction Cam...

Read this article

Explore More

Commercial Roofing News

TPO Roofing Systems
